The Martins Industries TC-18 Floor-to-Floor 18' Tire Conveyor is a heavy-duty, inclined belt conveyor engineered to streamline tire and wheel assembly handling between floor levels in automotive shops, tire warehouses, and mezzanine environments. Designed for high-throughput operations, it can transport up to 12 tires per minute up or down, dramatically reducing manual labor and the risk of handling injuries. Its raised, ground-anchored base delivers an ergonomic working height, while the plug-and-play design allows for rapid installation. Built with a powder-coated, UV-resistant steel frame and a heavy-duty 2-ply rubber belt, this conveyor delivers long-lasting performance in demanding commercial environments.
Features
High-throughput tire handling at a rate of up to 12 tires per minute to and from mezzanine levels
Heavy-duty 2-ply rubber belt supports loads up to 500 lbs for all tire and wheel assembly types
Angled PVC cleats spaced 60" center-to-center provide maximum stability for passenger car, SUV, and light truck tires
Dual control boxes at both ends of the conveyor with On, Off, Reverse, and Emergency Stop functions
Sealed precision ball bearings require zero maintenance over the life of the unit
1-HP motor with magnetic brakes keeps tires perfectly still when the conveyor is stopped
Secondary control box includes a 10' power cable for flexible placement within the shop or warehouse
Powder-coated, UV-resistant steel frame in gray and orange finish provides durability against environmental exposure
Plug-and-play design with a raised, ground-anchored base promotes ergonomic, injury-reducing operation
Specifications
Type: Floor-to-Floor Tire Conveyor
Product Dimensions (L x W x H): 216" x 29.5" x 11"
Net Weight: 825 lbs
Load Capacity: 500 lbs
Belt Width: 18"
Belt Material: Rubber (2-ply)
Belt Thickness: 3/8"
Speed: 17.7 m/min
Distance Between Cleats (Center-to-Center): 60"
Bearing Type: Sealed Precision Ball Bearing (No Maintenance)
Motor: 1 HP with Magnetic Brakes
Energy Type: Electricity
Voltage: 115V
Amperage: 12A
Wattage: 750W
Phase: 1
Hertz: 60 Hz
Controls: On / Off / Reverse / Emergency Stop at Each End
Frame Material: Steel
Finish: Powder Coated Paint, UV Resistant
Color: Gray and Orange
Certifications: CE, cETLus, UKCA, CSA Z432-16
Warranty: 1 Year
Includes
1x Heavy-Duty Rubber Belt (2-ply, 3/8" thickness)
1x Set of Angled PVC Cleats
1x Main Control Box
1x Secondary Control Box with 10' Power Cable
1x 1-HP Motor with Magnetic Brakes
1x User Manual
