The Coats HIT5000 is a heavy-duty truck tire changer engineered for professional shop environments handling tube and tubeless tires, including heavy-duty truck and agricultural applications. Built around a robust center carriage frame structure, the HIT5000 delivers reliable performance across a wide rim service range of 15 inches to 38 inches. A dual-direction hydraulic motor paired with heavy tapered roller bearings ensures smooth, consistent torque throughout every mounting and demounting cycle. This machine is designed to handle the most demanding commercial tire service tasks with precision and efficiency.
Features
Easy-to-use swing-arm houses all hydraulic controls with a dedicated lever for each powered function
Self-centering hydraulic clamping chuck for secure, consistent wheel engagement
Adjustable pressure regulator ensures proper matching of chuck pressure to rim strength
Heavy tapered roller bearings and a dual-direction hydraulic motor provide smooth torque delivery
Roller-type tire spreader included as standard equipment
Independent hook and roller mount/demount system for versatile tire handling
Moving table centered in frame for optimized workflow and operator access
Clamp arm lifting wheel lift system for safe and controlled tire positioning
Specifications
Operation: 3 Jaw Chuck
Wheel Types Handled: Budd & Dayton, Tube & Tubeless
Mount / Demount: Independent Hook & Roller
Tool Head Offset: Independent Removable, Mount in Table
Table Shape: Moving Table (Centered in Frame)
Wheel Clamping Method: 3 Jaw Chuck
Wheel Lift: Clamp Arm Lifting
Frame Structure: Center Carriage
Max Tire Diameter: 76 in (1930 mm)
Max Tire Width: 25 in (635 mm)
External Rim Diameter: 15 in - 38 in
Electric Specifications: 110V, 50/60 Hz, 1 Phase
Air Required: No
Max Chuck Torque: 2,900 ft/lbs
Max Overall Dimensions: 96 in (W) x 108 in (D) x 66 in (H)
Weight: 1,700 lbs
